In early 1996, Composite Design Co. developed E-Z Poxy to provide a replacement epoxy system for Epolite (Safe-T-Poxy) which is no longer produced by Hexcel. The E-Z Poxy series of laminating systems utilizes one resin and your choice of three hardeners for varying pot life and viscosity requirements. The E-Z Poxy systems offer the same handling and physical properties as the discontinued Epolite systems including ease of use, long pot life, rapid cure for demold or process continuation, and superior room temperature curing properties. Excellent for use in sport aviation, marine, and industrial applications.
E-Z 83 hardener is equivalent to Safe-T-Poxy standard hardener, E-Z 84 is equivalent to Safe-T-Poxy II hardener, and E-Z 87 is equivalent to Safe-T-Poxy slow hardener. E-Z Poxy products should not be mixed with materials produced by other epoxy manufacturers.
E-Z POXY TECHNICAL DATA
E-Z POXY RESIN SYSTEMS FROM COMPOSITE POLYMER DESIGN
E-Z 10 Epoxy Resin
E-Z 84 Aromatic Amine Hardener
E-Z 83 Aromatic Amine Hardener
E-Z 87 Aromatic Amin Hardener
E-Z 10 Resin (Viscosity 1500 cps @ 77F) with:
Hardener
EZ 83
EZ 84
EZ 87
Mixed Properties:
Mixed Viscosity cps @ 77F*
1300
800
1500
Viscosity Hardener cps @ 77F*
410
140
830
Pot Life @ 77F
2 hours
2 hours
5 hours
Tack Free @ 77F
4 hours
8 hours
8 hours
Cure Time @ 77F
24 hours
3 days
3 days
Mix Ratio by Volume
100/47
100/47
100/47
Mix Ratio by Weight
100/44
100/44
100/44
Physical Properties Tg (F):
R/T
151
151
142
P/C*
196
196
196
Elongation %
3.5
3.5
3.9
Specific Gravity
1.14
1.13
1.14
Linear Shrinkage @ 23C (4 days %)
.10
.10
.10
Tensile Strength PSI:
R/T
8,200
8,100
8,400
P/C
10,000
10,000
10,000
Tensile Modulus (PSI x 10 -5)
4.8
4.2
4.0
* Viscosity may vary +/- 10%
* Post Cure for 2 hrs. @ 150F
E-Z Poxy systems provide excellent room temperature curing systems for hand layup of composite parts and tooling. The systems are designed to provide ample working time with the varied pot life options while providing a rapid finish cure. Post curing these systems will increase their physical properties as designated in the above data, however, post cure is not required.
