MITCHELL MODULAR
GAUGE FRAMES

Modular gauge frames should be specified by part number plus identification of what function gauge (eg Oil Press., Ammeter, EGT) gets plugged in each location. Operating voltage of either 12 or 24 must also be specified. If operating voltage is not specified, 12 volt wiring will be provided.

All mounting frames include backplane connectors pre-wired with labeled 18 inch leads
Total Gauge Capacity
Configuration
Part No.
Price
Buy
1 Gauge
1 Gauge
10-02964
$53.50 ($58.32CAN)

8 Gauges
2 Wide 4 High
10-03915
$99.95 ($108.95CAN)

6 Gauges
1 Wide 6 High
10-02738
$80.00 ($87.20CAN)

Mitchell Instrument Clusters (Block Style)
Available in 6 gauge (pictured above) or 8 gauge clusters. On 8 gauge clusters, two additional gauges are added to the right side of the one pictured. Specify gauge and position desired for all cluster gauge positions. Prices are for the backplane (panel) only. Add price of each gauge for total cluster price.
Total Gauge Capacity
Configuration
Part No.
Price
Buy
6 Gauges
3 Wide 2 High
10-01708
$80.00 ($87.20CAN)
8 Gauges
4 Wide 2 High
10-01709
$93.50 ($101.92CAN)

Mitchell Instrument Clusters (Horizontal Style)
Available in 4 gauge (pictured), 5 gauge, or 6 gauge clusters. On 5 gauge and 6 gauge clusters, additional gauges are added to right side of the one pictured. Specify gauge and position desired for all cluster gauge positions. Prices are for the backplane (panel) only. Add price of each gauge for total cluster price.
Total Gauge Capacity
Configuration
Part No.
Price
Buy
2 Gauges
2 Wide 1 High
10-02739
$53.50 ($58.32CAN)
4 Gauges
4 Wide 1 High
10-01710
$66.75 ($72.76CAN)
5 Gauges
5 Wide 1 High
10-01711
$73.50 ($80.12CAN)

6 Gauges
6 Wide 1 High
10-01712
$80.00 ($87.20CAN)
