| Type |
Description |
Size |
Part |
Price |
Buy |
ALUMINUM
|
ER4043 |
A versatile alloy well suited for welding
6061T-6, 5005, and 6063. Extremely ductile. |
1/16" dia. |
P/N 03-27520 |
$10.25 ($11.17CAN) |
|
|
3/32" dia. |
P/N 03-27525 |
$8.25 ($8.99CAN) |
|
ER4145 |
Welding alloy recommended for use with
2024T3. A high strength alloy. |
1/16" dia. |
P/N 03-27510 |
$77.75 ($84.75CAN) |
|
|
3/32" dia. |
P/N 03-27515 |
$72.50 ($79.03CAN) |
|
ER5356 |
Combination of strength and ductility for
welding 5083, 5086, and 7000 series. Deposit can be anodized after welding. |
1/16" dia. |
P/N 03-27530 |
$8.75 ($9.54CAN) |
|
|
3/32" dia. |
P/N 03-27535 |
$8.95 ($9.76CAN) |
|
|
UTP4 |
Pure aluminum for 1100 grade. |
1/16" dia. |
P/N 03-27540 |
$19.99 ($21.79CAN) |
|
ER347 |
Popular aircraft type, stabilized austenitic
stainless alloy for welding 302 and 304 base materials. Excellent for welding
Ti stabilized grades such as 321 with high strength and elongation. |
1/16" dia. |
P/N 03-27545 |
$19.90 ($21.69CAN) |
|
|
3/32" dia. |
P/N 03-27550 |
$17.50 ($19.08CAN) |
|
|
UTP A-65 |
A multi alloy wire for a wide range of base materials
including stainless steel, low alloy high strength steel and especially
outstanding for dissimilar metals with over 120,000 psi tensile strength
and 25% elongation. Machinable. 1/16" dia. |
1/16" dia. |
P/N 03-27560 |
$33.40 ($36.41CAN) |
|
3/32" dia. |
P/N 03-27560 |
$39.50 ($43.05CAN) |
|
|
BRAZING
ALLOYS |
UTP 306M |
Cadmium free, low temperature silver brazing alloy
for high strength joints on stainless or copper. Exceptional for thin gauge
applications such as tubing. Flux coated for easy use. |
1/16" dia. |
P/N 03-27565 |
$362.95 ($395.62CAN) |
|
|
UTP 1M |
High strength, machinable torch rod for steel, brass,
bronze and other copper alloys. Easy to apply, high strength, and versatile
all purpose brazing rod. |
1/8" dia. |
P/N 03-27570 |
$21.60 ($23.54CAN) |
|
|
MAINTENANCE |
UTP 612 |
An all position mild steel coated electrode
for arc welding. Operates on AC or DC current and can be welded by even
the most inexperienced welder. 72,000 psi tensile strength and moisture
resistant. |
3/32" dia. |
P/N 03-27575 |
$7.70 ($8.39CAN) |
|
|
1/8" dia. |
P/N 03-27580 |
$9.95 ($10.85CAN) |
|
|
-- |
|
UTP Unial |
Self fluxing aluminum torch rod that can be applied
with even a butane torch. Low temperature, color matching and ideal for
repairs to tubing. |
- |
P/N 03-27585 |
$30.25 ($32.97CAN) |
|
