Pazmany Pl-4A Exploded Views

$100.00/Each
Quantity
Add to Wishlist
Part# 13-01513

Overview

Each sheet depicts one major assembly, all part numbers are shown. The builder can easily visualize each and all finished parts and how they go in assembly. With the construction manual and a set of plans, you the builder has the most complete information package available. Printed on heavy paper for durablity, 27pages one sided with 18 foldouts in 11x17.

California Prop 65 Warning Symbol

WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
