LYCOMING AT OVERHAUL PARTS REPLACEMENT LIST - TIO AND LTIO - 540-J2BD, N2BD, F2BD
| Vendor Part Number | Quantity Needed | Description | Part Number | Price Each | Quantity to Buy |
|---|---|---|---|---|---|
| SL12956 | 1 | Engine Gasket Set | 08-11583 | $310.00 | |
| SL3601-SC | 6 | SL3601-SC | 08-11751 | $68.75 | |
| SL13444-1 | 6 | SL13444-1 | 08-11595 | $69.85 | |
| SL16740A | 6 | Exhaust Valves | 08-11677 | $228.95 | |
| SL66713A | 6 | Intake Guides | 08-11816 | $22.50 | |
| MS13997-3 | 12 | Exhaust Valve Retaining Rings | 08-10802 | $5.50 | |
| SL13885 | 2 | Bearing Inserts (Main) | 08-11611 | $159.85 | |
| SL11575 | 6 | Bearing Inserts (Main) | 08-11526 | $47.70 | |
| SL74309A | 12 | Bearing Inserts (Connecting Rods) | 08-11937 | $22.50 | |
| SL75060 | 12 | Connecting Rod Bolts | 08-11955 | $51.75 | |
| SL12186 | 12 | Connecting Rod Nuts | 08-11567 | $3.45 | |
AN8-14A | 1 | Crankshaft Gear Bolt | AN8-14A | $1.93 | |
| SL71903A-A | 8 | Counterweight Bushings | 08-11870 | $8.75 | |
| SL15628 | 1 | Oil Seals Crankshaft | 08-11640 | $20.50 | |
| SL-STD-213 | 1 | Oil Seals Fuel Pump | 08-12036 | $7.50 | |
| SL14260 | 1 | Oil Seal Tach Drive | 08-11625 | $4.35 | |
| SL-STD-208 | 2 | Oil Seal Vacuum Pump | 08-12033 | $7.75 | |
| SL13641 | 2 | Magneto Drive Cushions | 08-11602 | $1.90 | |
| SL53E19600 | 1 | Thermostatic Bypass Valves | 08-11771 | $264.00 | |
| SL71667 | 1 | Lock Plates Fuel Pump Idler | 08-11866 | $2.68 | |
| STD-1737 | 1 | Retaining Rings Fuel Pump Idler | 08-12060 | $2.80 | |
| MS16625-2081 | 1 | Retaining Rings Camshaft | 08-10806 | $1.10 | |
| SL10451 | 6 | Cylinder Fin Stabilizers | 08-11514 | $5.75 | |
| SL10452 | 6 | Cylinder Fin Stabilizers | 08-11515 | $7.90 | |
| SL10450 | 6 | Cylinder Fin Stabilizers | 08-11513 | $9.50 | |
| SL-STD-1821 | 6 | Engine Hoses Oil Drainback Cylinder | 08-12031 | $1.60 | |
| SL76772 | 6 | Engine Hoses Upper Deck Vent | 08-11993 | $2.15 |
- JUMP TO
- Overview
- Reviews
- Q&A
- View in Catalog
Overview
|
Lycoming engines are the culmination of hundreds of parts improvements made over the last six decades. In Accordance with Textron-Lycoming Mandatory Service Bulletin 240R |
