STYROFOAM LARGE CELL

3 Reviews 6 Answered Questions
From $10.50 to $251.95
Main Image
Main Image
Foam Type Thick
(in.)		 Sheet Size
(in.)		 Part No. Price Buy
Styrofoam FB (Blue) Large Cell 2Lb/Cu. Ft.816 x 4
01-37600
$10.50
Quantity
Styrofoam FB (Blue) Large Cell 2Lb/Cu. Ft.816 x 25
01-01166
$57.80
Quantity
Styrofoam FB (Blue) Large Cell 2Lb/Cu. Ft.816 x 42
01-10600
$98.75
Quantity
Styrofoam FB (Blue) Large Cell 2Lb/Cu. Ft.816 x 67
01-10800
$154.95
Quantity
Styrofoam FB (Blue) Large Cell 2Lb/Cu. Ft.816 x 109
01-10900
$251.95
Quantity
Subtotal $0.00
Add to Wishlist

Overview

This blue large cell expanded foam is 2 lb. per cubic feet density and cuts easily using a hot wire to airfoil shapes. Compatible with most adhesives, but should be used only with epoxies, not polyester resins. Will dissolve in fuels and solvents. For structural use in building aircraft such as VariEze, Long-EZ, Cozy, etc.
  • Customers Also Viewed
  • Frequently Purchased With

Reviews

Submit a Review

I received my replacement product in perfect shipping condition. Thank You Aircraft Spruce.

Michael A
June 18, 2020

Excellent service and quick delivery. I found exactly what I needed and it arrived the day after I ordered it. Great experience from start to finish.

Jonah M
April 30, 2020

Great material for shaping with minimal shedding. Highly recommend this for laying up a part or filling voids

Roger
April 26, 2020

Q&A

Submit
Q: Is this material used to make small planes or like RC planes? I am confused.

This is a core material which is used in many sandwich construction composite aircraft, but can also be used to shape and make small scale models or RC planes.

Q: Is this large cell styrofoam compatible with POLY EPOXY STRUCTURAL EPOXY SYSTEM?

Yes, the epoxy systems we offer are compatible with the styrofoam and polyurethane foams we stock, Poly Epoxy included.

Q: I am looking at using some of the large cell Styrofoam for a project. I will need to adhere it some metal and am trying to figure out if I can use the adhesive I have or if it will eat away at the Styrofoam. Do you know what chemicals cannot be put on the foam?

It cannot be a solvent based adhesive which would consist of acetone or MEK. Epoxy adhesives are commonly used and will not hurt the foam.

Q: If you use this foam as a core for a sandwich layup, can it be postcured? If so, what is the maximum temperature that can be used without damaging the foam?

Max service temp is 165*F. You would first want to make a test panel and post cure at or below this temp to insure the safety of your part.

Q: Can this foam be cut with a hot wire?

Yes, large and small cell styrofoam can be cut with with a hot wire.

Q: The description says this is expanded foam. Is that a typo? EPS is not suitable for structural use in building aircraft. Since this is a homogenious closed-cell matrix, NOT made up of beads, isnt this product actually extruded foam (XPS)?

It is Dow XPS foam.
