UD-3-F Fuel Cap With Flat Adaptor

$109.75/Each
Part# 05-01061
MFR Model# UD-3-F
DescriptionPart Number
UD-3-F Fuel Cap with Flat Adaptor05-01061

Overview

The UD-3 flush fuel cap assembly is an unvented cap similar in design to the #5 style cap. The aluminum mounting ring has a 2" dia. opening and an overall dia. of 3-3/4 inch. It may be riveted, bolted or molded to the tank. It is currently used on many popular homebuilts such as the RV’s, Lancair, Velocity & White Lightning. Specify flat or contoured adapter.
