MILLENNIUM CYLINDER POWER ASSEMBLY KIT CONTENTS SA47006S-A21P FOR: O-470-K, L, R, S
| Vendor Part Number | Quantity Required | Description | Part Number | Price Each | Quantity to Buy |
|---|---|---|---|---|---|
| SA636242 | 1 | Guide | 08-11354 | $20.50 | |
| SA643766 + | 1 | Guide, Intake | 08-11425 | $17.95 | |
| SA630591 + | 1 | Insert | 08-11280 | $9.75 | |
| SA35967 + | 1 | Insert | 08-11002 | $26.50 | |
| MS9018-05/2-52 + | 2 | Helicoil | 08-10871 | $9.50 | |
| SA401893 + | 4 | Stud | 08-03682 | $4.35 | |
| MS122121 + | 4 | Helicoil | 08-10799 | $0.85 | |
| MS21209-C4-15 + | 2 | (12) Helicoil | 08-10818 | $1.00 | |
| SA47006S-A21P | 1 | Stud Assembly | 08-11062 | $1445.00 | |
| SA539988 | 1 | Valve, Intake | 08-11206 | $61.75 | |
| SA643873 | 1 | Valve, Exhaust | 08-03680 | $187.75 | |
| SA654441 | 2 | Spring | 08-11489 | $6.95 | |
| SA654442 | 2 | Spring | 08-11490 | $4.50 | |
| SA625393 | 2 | Valve Spring Retainer | 08-11213 | $1.15 | |
| SA629117-1 | 1 | Rotocoil | 08-11251 | $15.95 | |
| 646985 | 1 | Seal, Intake Guide | 08-11474 | $12.50 | |
| SA35971 | 1 | Retainer | 08-11004 | $11.80 | |
| SA652984 | 2 | Shaft, Rocker | 08-11488 | $17.35 | |
| SA652947 | 2 | Washer | 08-11487 | $0.37 | |
| MS90725-12 | 2 | Bolt, Rocker | 08-10874 | $0.70 | |
| SA625615 | 1 | Cover, Rocker Box | 08-11214 | $32.55 | |
| SA535118 | 8 | Screw, Rocker Box | 08-11173 | $1.20 | |
AN960-416L | 8 | Washer, Flat | AN960-416L | $0.03 | |
MS35338-44 | 8 | Washer | MS35338-44 | $0.03 | |
| SA4003 | 1 | Ring | 08-11042 | $31.50 | |
| SA4705 | 1 | Ring | 08-11070 | $36.50 | |
| SA4709 | 1 | Ring | 08-11077 | $9.50 | |
| SA532200 | 1 | Gasket, Molded Rubber | 08-03683 | $2.95 | |
| SA534610 | 4 | Seal | 08-03679 | $0.90 | |
| SA534857 | 1 | Gasket | 08-11165 | $6.50 | |
| SA536413 | 1 | Gasket | 08-03684 | $0.55 | |
| SA628260 | 1 | Gasket | 08-11240 | $7.50 |
- JUMP TO
- Overview
- Documents
- Reviews
- Q&A
- View in Catalog
Overview
|
Uniform hardness all the way through the steel barrel walls which allows the barrel to provide even wear while withstanding extreme cylinder temperatures and pressures. Exhaust and intake ports are volumetrically matched to maximum output and performance. Increased port wall thickness - eliminates problems with warping and cracking. Computer-generated head fin configuration - deliver more uniform heat transfer and fewer "hot" spots. Manufactured from the most advanced alloys available - exceed industry standard for strength and porosity. + Included with stud assembly. |
Documents
- Technical Specifications (PDF)
Reviews
Quality part !!
Verified Purchase
WASHER, FLAT AN960-416L NAS1149F0432P
Verified Purchase
WASHER, FLAT AN960-416L NAS1149F0432P
Verified Purchase
SUPERIOR SA643873 EXHAUST VALVE
Verified Purchase
WASHER, FLAT AN960-416L NAS1149F0432P
Quality product
Verified Purchase
WASHER, FLAT AN960-416L NAS1149F0432P
very helpful staff
I got this just incase I tore the other valve cover gasket. (SA534857). Turned out it was the same one I had already on the valve cover. I thought it was the cheap cork, this was a nice gasket. For $2.66 it was well worth it.
