MILLENNIUM CYLINDER POWER ASSEMBLY KIT CONTENTS SA52006-A22P FOR: TSIO-520-AF, B, BB, C, CE, D, DB, E, EB, G, H, J, JB, K KB, L, LB, M, N, NB, P, R, T, UB, VB, WB
| Vendor Part Number | Quantity | Description | Part Number | Price Each | Quantity to Buy |
|---|---|---|---|---|---|
| SA35967 + | 1 | Insert | 08-11002 | $26.50 | |
| SA636242 + | 1 | Guide | 08-11354 | $20.50 | |
| SA642318 + | 1 | Valve Seat Insert | 08-11402 | $28.50 | |
| SA643766 + | 1 | Guide | 08-11425 | $17.95 | |
| MS122121 + | 4 | Heli-Coil | 08-10799 | $0.85 | |
| MS21209-C4-15 + | 2 | Heli-Coil | 08-10818 | $1.00 | |
| SA638125 + | 4 | Stud | 08-03688 | $10.85 | |
| 2-107 | 2 | Helicoil | 08-12035 | $3.60 | |
| SA52006-A22P | 1 | Stud Assembly | 08-11099 | $1525.00 | |
| SA35971 | 1 | Retainer | 08-11004 | $11.80 | |
| SA539988 | 1 | Valve | 08-11206 | $61.75 | |
| SA625393 | 2 | Valve Spring Retainer | 08-11213 | $1.15 | |
| SA629117-1 | 1 | Rotocoil Assy | 08-11251 | $15.95 | |
| SA654441 | 2 | Spring-Valve Outer | 08-11489 | $6.95 | |
| SA654442 | 2 | Spring-Valve Inner | 08-11490 | $4.50 | |
| SA643873 | 1 | Valve | 08-03680 | $187.75 | |
| 646985 | 1 | Seal | 08-11474 | $12.50 | |
| MS90725-12 | 2 | Bolt | 08-10874 | $0.70 | |
| SA652947 | 2 | Washer | 08-11487 | $0.37 | |
| SA652984 | 2 | Shaft | 08-11488 | $17.35 | |
| SA625615 | 1 | 520 Valve Cover | 08-11214 | $32.55 | |
| SA535118 | 8 | Screw | 08-11173 | $1.20 | |
MS35338-44 | 8 | Washer-Split Lock | MS35338-44 | $0.03 | |
AN960-416L | 8 | Washer | AN960-416L | $0.02 | |
| SA5004 | 1 | Ring | 08-11092 | $36.80 | |
| SA5208 | 1 | Ring | 08-11106 | $31.50 | |
| SA5209 | 1 | Ring | 08-11110 | $10.80 | |
| SA534610 | 4 | Seal | 08-03679 | $0.90 | |
| SA534857 | 1 | Gasket | 08-11165 | $6.50 | |
| SA536413 | 1 | Gasket | 08-03684 | $0.55 | |
| SA628260 | 1 | Gasket-Exhaust | 08-11240 | $7.50 | |
| SA630979-9 | 2 | O-Ring | 08-11295 | $1.35 | |
| SA640612 | 1 | Washer | 08-11389 | $0.55 | |
| SA641066 | 1 | Packing | 08-03689 | $5.95 |
- JUMP TO
- Overview
- Documents
- Reviews
- Q&A
- View in Catalog
Overview
|
Uniform hardness all the way through the steel barrel walls which allows the barrel to provide even wear while withstanding extreme cylinder temperatures and pressures. Exhaust and intake ports are volumetrically matched to maximum output and performance. Increased port wall thickness - eliminates problems with warping and cracking. Computer-generated head fin configuration - deliver more uniform heat transfer and fewer "hot" spots. Manufactured from the most advanced alloys available - exceed industry standard for strength and porosity. + Included with stud assembly. |
Documents
- Technical Specifications (PDF)
Reviews
Quality part !!
Verified Purchase
WASHER, FLAT AN960-416L NAS1149F0432P
Verified Purchase
WASHER, FLAT AN960-416L NAS1149F0432P
Verified Purchase
SUPERIOR SA643873 EXHAUST VALVE
Verified Purchase
WASHER, FLAT AN960-416L NAS1149F0432P
Quality product
Verified Purchase
WASHER, FLAT AN960-416L NAS1149F0432P
Superior products are...Superior
It arrived on time and was complete package to replace the cylinder on my 310
Q&A
Please note, Aircraft Spruce's personnel are not certified aircraft mechanics and can only provide general support and ideas, which should not be relied upon or implemented in lieu of consulting an A&P or other qualified technician. Aircraft Spruce assumes no responsibility or liability for any issue or problem which may arise from any repair, modification or other work done from this knowledge base. Any product eligibility information provided here is based on general application guides and we recommend always referring to your specific aircraft parts manual, the parts manufacturer or consulting with a qualified mechanic.
Yes, the difference is the manufacturer. Yes, the manufacturer of SA30979-9 has FAA-PMA approval as a replacement for 630979-9.
