7/8" x 11/16" x 1-3/8"
.629" Diameter (16 mm)
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
Although this is a straight forward product, you MUST HAVE the Lamp Removal Tool (EAO Product Number 02-906 for Incandescent Bulb) or (EAO Product Number 61-9740.0 for LED Version). You should also have the Lens Removal Tool (EAO Product Number 02-905). Aircraft Spruce sells the replacement bulbs (Incandescent Only), however they DO NOT offer the removal tools. These lens / bulb removal tools are vital. This product is the EAO Series 31 Indicator. A web search will show the PDF product profile with the required removal tools you need. Before purchasing, ask if Aircraft Spruce offers the removal tools. They should have from the start. We learned the hard way.
Please note, Aircraft Spruce's personnel are not certified aircraft mechanics and can only provide general support and ideas, which should not be relied upon or implemented in lieu of consulting an A&P or other qualified technician. Aircraft Spruce assumes no responsibility or liability for any issue or problem which may arise from any repair, modification or other work done from this knowledge base. Any product eligibility information provided here is based on general application guides and we recommend always referring to your specific aircraft parts manual, the parts manufacturer or consulting with a qualified mechanic.
11-06000 comes with the 12V bulb. To make it a 24V, just purchase the additional 24V Replacement Bulb (Part Number 31-963.2) which can be found on this webpage under the "Accessories" tab and switch the bulbs once you receive the order.
Yes, the legend lights are available in Red, Blue, Green, Orange, Yellow, and Clear. You need to choose using the drop down selector on this page.
They are not LED. The bulbs are 80mA.
Looks to be 5A per the data sheet.
