BARRACUDA RAW MATERIALS

0 Reviews 0 Answered Questions

From $956.02 to $3753.54

Description	Part Number	Price	Buy
BARRACUDA WOOD KIT #1 PLYWOOD Click Here for Kit Components	01-00577	$3018.64	Quantity
BARRACUDA WOOD KIT #2 WING Click Here for Kit Components	01-00616	$2111.23	Quantity
BARRACUDA WOOD KIT #3 SPARS Click Here for Kit Components	01-00617	$956.02	Quantity
BARRACUDA WOOD KIT #4 BODY Click Here for Kit Components	01-00618	$1648.20	Quantity
BARRACUDA RAW MATERIALS KIT Click Here for Kit Components	01-00619	$1130.05	Quantity
BARRACUDA FASTENER/HARDWARE KT Click Here for Kit Components	01-00621	$3753.54	Quantity

Subtotal $0.00

Add to Wishlist

JUMP TO

JUMP TO
Overview
Builders Forum
Reviews
Q&A
View in Catalog

Overview

These are replacement raw materials for the Barracuda.

Builders Forum

Customers Also Viewed

Reviews

Submit a Review

Q&A

View in Catalog

Question About:	Barracuda Raw Materials
Email:
Your Name:
Question:
	Submit

Review Product:	Barracuda Raw Materials
Email:
Your Name:
Rating:
Comments:
	Submit

Component	Quantity	Price
02-19180DOM MAHOG PLYWOOD 3/32X4X8 90*	4	$153.75
02-19320DOM MAHOG PLYWOOD 1/8X2X8 90*	1	$76.99
02-19380DOM MAHOG PLYWOOD 1/8X4X8 90*	2	$153.95
02-20300FINNISH BIRCH 48"X48" X 0.8MM	6	$37.50
02-20400FINNISH BIRCH 48"X48" X 1.5MM	1	$44.50
02-20500FINNISH BIRCH 48"X48" X 2.5MM	8	$72.75
02-20800FINNISH BIRCH 48"X48" X 6MM	1	$129.75
02-24380DOM BIRCH PLYWOOD 1/16X4X8 90*	10	$103.75

Component	Quantity	Price
02-11SPRUCE CAPSTRIP 1" X 1"	26	$4.00
02-11300CAPSTRIP 1/4" X 1/4"	50	$0.33
02-11900CAPSTRIP 1/4" X 3/4"	14	$0.70
02-12CAPSTRIP 1" X 2"	3	$5.50
02-12000CAPSTRIP 1/2" X 1/2"	120	$1.12
02-121CAPSTRIP 1/2" X 1"	24	$2.05
02-123SPRUCE 1/2 X NOM 3	63	$7.50
02-124SPRUCE 1/2 X NOM 4	4	$9.50
02-142CAPSTRIP 1/4" X 2"	14	$1.87
02-143SPRUCE 1/4 X NOM 3	5	$3.80
02-14800CAPSTRIP 1/2" X 3/4"	8	$1.62
02-1612SPRUCE 1 X NOM 6-1/2	13	$15.00
02-31638CAPSTRIP 3/16" X 3/8"	70	$0.40
02-344SPRUCE 3/4 X NOM 4	18	$9.50
02-34512SPRUCE 3/4 X NOM 5-1/2	7	$11.50
02-381CAPSTRIP 3/8" X 1"	15	$1.95
02-3812CAPSTRIP 3/8" X 1/2"	32	$0.98
02-382CAPSTRIP 3/8" X 2"	8	$3.55
02-3834CAPSTRIP 3/8" X 3/4"	28	$1.48
02-3838CAPSTRIP 3/8" X 3/8"	370	$0.72
02-384SPRUCE 3/8 X NOM 4	29	$9.50
02-3878CAPSTRIP 3/8" X 7/8	16	$1.74
02-583SPRUCE 5/8 X NOM 3	5	$7.50

Component	Quantity	Price
02-00088	1	N/A
02-12312SPRUCE 1/2 X NOM 3-1/2	6	$7.50
02-15SPRUCE 1 X NOM 5	43	$14.25
02-34312SPRUCE 3/4 X NOM 3-1/2	38	$7.50

BARRACUDA RAW MATERIALS

Overview

Builders Forum

Reviews

Q&A

View in Catalog

01-00577BARRACUDA WOOD KIT #1 PLYWOOD

01-00616BARRACUDA WOOD KIT #2 WING

01-00617BARRACUDA WOOD KIT #3 SPARS

01-00618BARRACUDA WOOD KIT #4 BODY

01-00619BARRACUDA RAW MATERIALS KIT

01-00621BARRACUDA FASTENER/HARDWARE KT

Component	Quantity	Price
03-005004130 STEEL TUBE 1/4" X .058	6	$13.50
03-025004130 STEEL TUBE 1/2" X .049	5	$4.35
03-027004130 TUBE 1/2" X .065	1	$7.50
03-027104130 STEEL TUBE 1/2" X .083	1	$7.99
03-032004130 STEEL TUBE 9/16" X .065	1	$9.25
03-037004130 STEEL TUBE 5/8" X .049	2	$4.65
03-039004130 STEEL TUBE 5/8" X .065	1	$6.80
03-044004130 STEEL TUBE 3/4" X .049	19	$3.55
03-045004130 STEEL TUBE 3/4" X .058	7	$4.55
03-055004130 STEEL TUBE 7/8" X .058	1	$4.55
03-060004130 STEEL TUBE 7/8 X .188	4	$12.50
03-062004130 STEEL TUBE 1" X .049	6	$3.75
03-064004130 STEEL TUBE 1" X .065	5	$4.60
03-071004130 STEEL TUBE 1-1/8" X .058	3	$4.90
03-080004130 STEEL TUBE 1-1/4" X .120	2	$9.90
03-105004130 STEEL TUBE 1-3/4" X .120	3	$9.85
03-108004130 STEEL TUBE 2" X .065	1	$10.50
03-110004130 TUBE 2" X .120	4	$12.75
03-111004130 STEEL TUBE 2-1/4" X .120	2	$17.60
03-137004130 SQ TUBE 1" X 1" X .065	8	$15.50
03-236004130 STEEL SHEET 18X18X.063	1	$21.75
03-255004130 SHEET 18 X 18 X .125	3	$42.50
03-279202024T3 ALUM SHEET .025 4X8	1	$120.75
03-283502024T3 ALUM SHEET .063 2X4	1	$57.99
03-418002024T3 ROUND ALUM T3511 ROD 1/2"	1	$2.85
03-419002024T3 ROUND ALUM. ROD 5/8	8	$4.65
03-422002024T3 ROUND BAR 1"	2	$10.50
03-452002024T3 RECT 3/4" X 2-1/2"	5	$20.50
AN6-20BOLT DRILLED AN6-20	2	$1.06
AN8-30BOLT DRILLED AN8-30	2	$4.35

Component	Quantity	Price
04-01650FLANGED BUSHING FF303-01	2	$0.25
04-05800AEROQUIP STEEL ELBOW 2071-6-6S	2	$5.55
05-03451BC4W10 BELLCRANK BEARING	12	$24.95
05-17700FINGER STRAINERS - STANDARD	2	$7.70
303-4EATON AEROQUIP HOSE 303-4 1/4"	16	$7.85
303-6EATON AEROQUIP HOSE 303-6	8	$9.50
491-4AEROQUIP HOSE FITTINGS 491-4	6	$13.25
491-6AEROQUIP HOSE FITTING 491-6	6	$18.75
AN3-10BOLT DRILLED AN3-10	8	$0.62
AN310-3NUT, CASTLE AN310-3	12	$0.67
AN310-4NUT, CASTLE AN310-4	28	$0.94
AN310-5NUT, CASTLE AN310-5	7	$1.11
AN310-6NUT, CASTLE AN310-6	14	$1.39
AN3-10ABOLT UNDRILLED AN3-10A	2	$0.14
AN3-11BOLT DRILLED AN3-11	2	$0.74
AN3-11ABOLT UNDRILLED AN3-11A	2	$0.18
AN3-12BOLT DRILLED AN3-12	2	$0.78
AN3-12ABOLT UNDRILLED AN3-12A	4	$0.19
AN3-13ABOLT UNDRILLED AN3-13A	2	$0.19
AN3-14ABOLT UNDRILLED AN3-14A	2	$0.18
AN3-15ABOLT UNDRILLED AN3-15A	4	$0.28
AN316-4RNUT, THIN CHECK AN316-4R	8	$0.09
AN316-5RNUT, THIN CHECK AN316-5R	10	$0.13
AN316-6RNUT, THIN CHECK AN316-6R	3	$0.15
AN3-16ABOLT UNDRILLED AN3-16A	8	$0.22
AN3-17ABOLT UNDRILLED AN3-17A	4	$0.21
AN3-20ABOLT UNDRILLED AN3-20A	2	$0.26
AN3-21ABOLT UNDRILLED AN3-21A	6	$0.26
AN3-25ABOLT UNDRILLED AN3-25A	2	$0.46
AN3-26ABOLT UNDRILLED AN3-26A	4	$0.39
AN3-33ABOLT UNDRILLED AN3-33A	4	$0.64
AN3-4ABOLT UNDRILLED AN3-4A	12	$0.11
AN3-5ABOLT UNDRILLED AN3-5A	6	$0.11
AN3-6BOLT DRILLED AN3-6	4	$0.87
AN363-1032STOP NUT AN363-1032 MS21045-3	140	$0.38
AN363-428STOP NUT AN363-428 MS21045-4	60	$0.46
AN363-624STOP NUT MS21045-6	23	$0.74
AN363-820MS21045-8 NUT STOP	8	$1.50
AN3-7BOLT DRILLED AN3-7	6	$0.63
AN3-7ABOLT UNDRILLED AN3-7A	3	$0.12
AN393-11CLEVIS PIN MS20392-2C11	3	$0.61
AN4-11BOLT DRILLED AN4-11	4	$0.78
AN4-11ABOLT UNDRILLED AN4-11A	4	$0.28
AN4-12BOLT DRILLED AN4-12	2	$0.83
AN4-12ABOLT UNDRILLED AN4-12A	4	$0.28
AN4-13ABOLT UNDRILLED AN4-13A	2	$0.28
AN4-14ABOLT UNDRILLED AN4-14A	20	$0.29
AN4-15ABOLT UNDRILLED AN4-15A	4	$0.35
AN4-16BOLT DRILLED AN4-16	4	$1.05
AN4-17BOLT DRILLED AN4-17	4	$1.05
AN4-23BOLT DRILLED AN4-23	4	$1.18
AN4-25ABOLT UNDRILLED AN4-25A	6	$0.68
AN4-35ABOLT UNDRILLED AN4-35A	2	$0.98
AN4-3AAN4-3A BOLT UNDRILLED	2	$0.21
AN490HT10PTHREADED ROD ENDS AN490HT10P	10	$17.65
AN490HT6PTHREADED ROD ENDS AN490HT6P	8	$17.50
AN5-11BOLT DRILLED AN5-11	2	$1.08
AN5-12BOLT DRILLED AN5-12	1	$1.81
AN5-36BOLT DRILLED AN5-36	1	$1.74
AN5-44ABOLT UNDRILLED AN5-44A	2	$1.97
AN5-45BOLT DRILLED AN5-45	1	$3.35
AN6-12ABOLT UNDRILLED AN6-12A	1	$0.56
AN6-14BOLT DRILLED AN6-14	2	$1.41
AN6-14ABOLT UNDRILLED AN6-14A	6	$0.69
AN6-16ABOLT UNDRILLED AN6-16A	8	$0.94
AN6-7BOLT DRILLED AN6-7	2	$0.90
AN816-4DAN FITTINGS AN816-4D NIPPLE	2	$2.57
AN816-6DAN FITTINGS AN816-6D NIPPLE	4	$3.65
AN818-4DAN FITTINGS AN818-4D NUT	17	$0.80
AN818-6DAN818-6D AN FITTING NUT	4	$0.93
AN819-4DAN FITTINGS AN819-4D SLEEVE	17	$0.82
AN819-6DAN819-6D AN FITTING SLEEVE	4	$0.95
AN822-4DAN FITTINGS AN822-4D ELBOW	6	$9.55
AN823-4DAN FITTINGS AN823-4D ELBOW	2	$12.70
AN824-4DAN FITTINGS AN824-4D TEE	1	$11.50
AN827-4DAN FITTINGS AN827-4D CROSS	2	$21.50
AN832-4DAN FITTINGS AN832-4D UNION	4	$4.75
AN833-6DAN FITTINGS AN833-6D ELBOW	2	$17.99
AN924-4DAN FITTINGS AN924-4D NUT	8	$1.00
AN924-6DAN FITTINGS AN924-6D NUT	4	$1.42
AN960-10WASHER, FLAT AN960-10	140	$0.02
AN960-10LWASHER, FLAT AN960-10L	20	$0.02
AN960-416WASHER, FLAT AN960-416	60	$0.04
AN960-416LWASHER, FLAT AN960-416L NAS1149F0432P	30	$0.02
AN960-516WASHER, FLAT AN960-516	20	$0.04
AN960-516LNAS1149F0532P WASHER, FLAT	20	$0.03
AN960-616WASHER, FLAT AN960-616	25	$0.04
AN960-616LWASHER, FLAT AN960-616L	10	$0.03
AN960-816WASHER, FLAT AN960-816	18	$0.07
AN970-3WASHER, FLAT AN970-3	180	$0.08
AN970-4WASHER, FLAT AN970-4	32	$0.10
AN970-6WASHER, FLAT AN970-6	10	$0.21
AN970-8WASHER, FLAT AN970-8	8	$0.63
MS20220-1PULLEYS MS20220-1	2	$28.50
MS20220-2PULLEYS MS20220-2	7	$34.50
MS24694-S111MACHINE SCREW # MS24694-S111	8	$0.29
MS24694-S54MACHINE SCREW # MS24694-S54	4	$0.15
MS24694-S60MACHINE SCREW # MS24694-S60	4	$0.18
MS24694-S64MACHINE SCREW # MS24694-S64	8	$0.21
MS24694-S66MACHINE SCREW # MS24694-S66	2	$0.23
MS24694-S72MACHINE SCREW # MS24694-S72	6	$0.44
MS24694-S82MACHINE SCREW # MS24694-S82	1	$0.63
MW-6AURORA BEARING MW-6	3	$8.95
NAS6204-10SHEAR BOLT NAS6204-10	8	$0.42
NAS6204-6SHEAR BOLT NAS6204-6	2	$0.38
RE3F4REP3F4 BEARING MS21153-3	8	$95.75
REP4F5BEARINGS REP4F5FS464	10	$69.85
