MILLENNIUM CYLINDER POWER ASSEMBLY KIT CONTENTS SL32006N-A21P FOR: O-320-C (LOW COMPRESSION)
| Vendor Part Number | Quantity | Description | Part Number | Price Each | Quantity to Buy |
|---|---|---|---|---|---|
| SL61681A + | 1 | Guide, Intake | 08-11803 | $21.50 | |
| SL72057A + | 1 | Seat, Intake | 08-11875 | $44.60 | |
| SL72058A + | 1 | Seat, Exhaust | 08-11876 | $43.60 | |
| SL74230A + | 1 | Guide, Exhaust | 08-11929 | $19.85 | |
| MS20823-8D + | 1 | Elbow | 08-10815 | $26.50 | |
| MS9018-05/2-52 + | 2 | Helicoil | 08-10871 | $9.50 | |
| SL-STD-1872 + | 2 | Helicoil | 08-12032 | $1.74 | |
| MS49005-2 + | 2 | Plug | 08-10863 | $1.25 | |
| SL31C-12 + | 2 | Stud | 08-03636 | $4.95 | |
| SL25C-9 + | 1 | Stud | 08-11713 | $6.50 | |
| SL66610 | 4 | Bushing | 08-11814 | $1.15 | |
| SL13445 | 1 | Piston Pin | 08-11596 | $57.75 | |
60828 | 2 | Piston Pin Plugs | 60828 | $19.90 | |
| MS13998-3 | 1 | Cap | 08-10803 | $6.70 | |
| MS13997-3 | 2 | Key | 08-10802 | $5.50 | |
| SL10077 | 1 | Valve Spring Seat | 08-11502 | $9.50 | |
| SL11795 | 2 | Spring | 08-11538 | $9.50 | |
| SL11800 | 2 | Spring | 08-11541 | $11.85 | |
| SL13323 | 1 | Valve Spring Seat | 08-11591 | $10.50 | |
| SL16475 | 1 | Valve Spring Seat | 08-11667 | $11.50 | |
| SL19001A | 1 | Valve, Exhaust | 08-11697 | $199.85 | |
| SL73938 | 1 | Key | 08-11922 | $69.95 | |
| SL65441 | 1 | Spring Seat | 08-11812 | $10.50 | |
| SL12272 | 1 | Lock Plate | 08-11568 | $0.98 | |
| SL18661 | 2 | Seal | 08-00293 | $1.85 | |
| SL71481 | 1 | Cylinder Base Seal | 08-03637 | $2.70 | |
| SL71973 | 1 | Gasket | 08-11872 | $0.75 | |
| SL75906 | 1 | Gasket, Rocker Box | 08-11983 | $1.65 | |
| SL13790A | 1 | Shaft, Rocker | 08-11603 | $16.95 | |
| SL12892 | 2 | Thrust Button | 08-11579 | $2.85 | |
| SL14995 | 1 | Spring | 08-11629 | $3.35 | |
| SL61247 | 1 | Cover, Rocker Box | 08-11788 | $24.65 | |
| SL74241A | 2 | Ring, Piston | 08-11934 | $27.50 | |
| SL73857A | 1 | Ring, Piston | 08-03694 | $29.50 |
- JUMP TO
- Overview
- Documents
- Reviews
- Q&A
- View in Catalog
Overview
|
Uniform hardness all the way through the steel barrel walls which allows the barrel to provide even wear while withstanding extreme cylinder temperatures and pressures. Exhaust and intake ports are volumetrically matched to maximum output and performance. Increased port wall thickness - eliminates problems with warping and cracking. Computer-generated head fin configuration - deliver more uniform heat transfer and fewer "hot" spots. Manufactured from the most advanced alloys available - exceed industry standard for strength and porosity. + Included with stud assembly. |
Documents
- Technical Specifications (PDF)
Reviews
It’s a pin plug. It fit. What else is there to say? Five out of five, would recommend.
Verified Purchase
60828 LYCOMING PISTON PIN PLUG
good
Verified Purchase
SUPERIOR SL13790A SHAFT, ROCKER VALVE
Q&A
Please note, Aircraft Spruce's personnel are not certified aircraft mechanics and can only provide general support and ideas, which should not be relied upon or implemented in lieu of consulting an A&P or other qualified technician. Aircraft Spruce assumes no responsibility or liability for any issue or problem which may arise from any repair, modification or other work done from this knowledge base. Any product eligibility information provided here is based on general application guides and we recommend always referring to your specific aircraft parts manual, the parts manufacturer or consulting with a qualified mechanic.
