NavStrobe Wingtip Navigation Light with Constant & Fast Strobe 45w FAA-TSO

Select Color:
RedGreen
Quantity
Add to Wishlist

Overview

These bulbs are standard parts and are certified to be FAA TSO-C30c Approved.

Emitter Type: Green Cree LEDís

Turn on first: Constant lighting / Turn on second time <3s: Fast Strobe. Switch between modes in fog/cloud etc.

Note: This product must be used in conjunction with Aircraft Wingtip Navigation Light Clear Lens Cover ( Sextant A-1233A-1) to be compliant.

Specifications

  • Power: 45W Equivalent
  • Color BIN: Aviation Green (520-535nm)
  • Rated Voltage: 10-30VDC
  • Draws <460ma @ 14.2VDC
  • Luminous Flux: 1150LM/91.7cdl (0/0 degrees) 225.7LM/18.1cdl (+/-90 degrees),
  • 2 modes: constant & fast strobe
  • Base Type: BAY15s = Single contact and offset pin. (A-1512)
  • Application: Wingtip Navigation Light replacement.
  • Contains 1 light bulb per pack.
  • Dimensions: 2.0 in x 0.7 in (52mm x 1.8cm).
  • Weight: 0.32 oz (9 g)

Dimensional Drawing

Documents

  • Accessories
  • Customers Also Viewed
  • Frequently Purchased With
  • Related Items

Reviews

Packaging was poor for a 140.00 bulb.not sure about quality control for an item thats STC

Tscm G Verified Purchase

NAVSTROBE WINGTIP GREEN 45 WATT

April 7, 2022

Arrived DOA, not sure if they bench test these.Packaging was poor for a 140.00 bulb. Love the concept, not sure about quality control for this as an STC item

Tscm G Verified Purchase

NAVSTROBE WINGTIP RED 45 WATT

April 7, 2022
