ICOM A25C VHF AIR BAND COM RADIO - LITHIUM BATTERY

Select Voltage:
110V220V
Quantity
Add to Wishlist

Overview

The A25C is a powerful air band handheld with 6 watts of power and an IP57 waterproof rating; weather cannot stop these radios. The handheld includes a large 2350mAh Li-ion battery, providing a long operating time. The easy-to-use interface and large 2.3-inch LCD display combine to provide stress-free programming and in-flight operation.
  • Output power: 6W typ. (PEP), 1.8W (CW)
  • Frequencies: TX (COM); 118.00-136.975MHz
    RX (COM) ; 108.00-136.975MHz
    RX (Weather); 161.650-163.275MHz
  • Channel spacing: 8.33/25KhZ
  • Channels: 200 (20CH x 10 banks)
  • Battery life: 2350mAh Li-ion battery, up to 10.5 hours
    Typical operation with Tx:Rx:Stand-by duty ratio = 5:5:90, Power save ON
  • Version: Communications only
Large easy to use LCD
The A25s large 2.3-inch LCD provides user-friendly, graphic screens. The day mode allows pilots to view the screen in direct sunlight and the night mode makes it easy to read in the dark.

Features

  • IP57 dust-protection and waterproof construction
  • "Flip-flop" channel recall
  • Smart battery with detailed battery status
  • 121.5MHz emergency key
  • Weather channels
  • Priority watch
  • VFO scan, memory-channel scan, priority scan
  • ANL (Auto Noise Limiter) for noise reduction
  • Side tone function
  • Internal VOX capability

Specifications

General
COM A25C
COM channels
Frequency Coverage
Tx
Rx
RX (Weather)
A25C
118.000-136.975 MHz
118.000-136.975 MHz
161.650-163.275 MHz
Channel spacing 25/8.33 kHz
Type of emission 6K00A3E, 5K60A3E, 16K0G3E (Weather)
Power supply requirement 7.2 V DC (BP-288), 11.0 V DC (External DC Jack)
Current drain (approximately)
Tx High
Rx Max. audio/Stand-by

Less than 1.8 A
Less than 500 mA/90 mA typ.
Antenna impedance 50 Ω
Operating Temperature Range 10C to +60C; 14F to 140F
Dimensions (WHD)
(projections not included)
58.9 148.4 31.8 mm; 2.3 5.8 1.3 in
Weight (approximately) 340 g; 12.0 oz (with BP-288)
Transmitter
Output power (at 7.2 V DC) 6.0/1.8 W typical (PEP/carrier)
Audio harmonic distortion Less than 10% (at 60% modulation)
Hum and noise ratio More than 35 dB
Spurious emissions More than 46 dB
(Exclude fc62.5 kHz for AM mode)
(Exclude fc20.825 kHz for AM-N mode)
Frequency stability 0.4 kHz
Receiver
Intermediate frequencies
1st
2nd

46.35 MHz
450 kHz
Sensitivity (typ)
COM (6 dB S/N)
WX (12 dB SINAD)

Less than 0 dBμ
Less than 8 dBμ
Squelch sensitivity (at threshold) Less than 0 dBμ (AM), Less than 5 dBμ (FM)
Audio output power More than 350 mW typ. (8 Ω load/60% Mod. at 10% distortion)
Hum and noise More than 35 dB (at 30% modulation)
Spurious response More than 60 dB (AM), More than 30 dB (FM)
Audio output power More than 350 mW typ. (8 Ω load/60% Mod. at 10% distortion)
Ext. speaker connector 3-conductor 3.5 (d) mm (1⁄8ʺ)/8 Ω

In The Box

  • Antenna
  • Belt Clip
  • Handstrap
  • Battery Case
  • Battery Pack
  • Headset Adapter
  • Power Adapter
  • Battery Charger
  • Accessories
  • Customers Also Viewed
  • Frequently Purchased With
  • Related Items

Reviews

Bought the ICOM A25C for my husband. He is very pleased, and the radio is very clear. Thank you to Spruce aircraft for their helpful advice.

C. B
September 15, 2020

A great radio that is easy to use. I was pleasantly surprised to find the charger is multi-voltage as I will be using the radio in 110V and 240V countries. It was also a surprise to find a separate battery pack for AA batteries included.

Fighter F
January 17, 2020

Q&A

Q: What is the difference between the Icom A25C and the Icom A25N?

The A25C is comm only, meaning that it is for communication only does not have NAV features. The A25N is a NAV/COM, meaning that it has communication and VOR navigation built in.
