Pilot USA PA-200V 2 Place Intercom For Yaesu Fta-450L/550/750L/850L Radios

$177.75/Each
Quantity
Add to Wishlist
Part# 11-03545
MFR Model# PA-200V

Overview

The PA-200V is a 2 Place Mono Intercom designed to be used with your YAESU/VERTEX handheld transceiver.

This unit will plug directly into YAESU FTA-450L, FTA-550, FTA-750L and VERTEX VXA-100, VXA-150 Transceivers.

California Prop 65 Warning Symbol

WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.

Features

  • Portable & Compact
  • Pilot / Co-Pilot Volume Control
  • Voice Activated (VOX)
  • Adjustable Squelch Circuit
  • Fail Safe Mode
  • Easy Battery Access
  • Powered by 9V Battery
  • 25-30 Hours Battery Life
  • Includes a PTT (Push to Talk) Switch

Specifications

  • Dimensions 2.25'' x 2.75'' x 1.25''
  • Cord Type 5 Foot Straight
  • Plug Type 3.5mm (4 pole) Straight Angle Plug
  • Product Weight 4.2 ounces (119 grams)
  • Shipping Weight 1.50
  • Accessories
  • Frequently Purchased With
  • Customers Also Viewed

Reviews

Volume control did not work. Returned product.

Calvin A Verified Purchase

PILOT TRANS INTERCOM PA-200V

October 16, 2021

Unlike the stick headset connector that Yaesu provides, this units connector is simply a plug with no threaded screws to hold it secure. The plug is VERY temperamental about seating correctly and need constant pressure to stay in the proper seated position. Otherwise is squeals pops squawks and makes tons of feedback. If they would change the plug to the type that screws in and is secure I would give the unit 5 stars , but as it is it is undependable and at any time can start making so much noise you have to unplug it. Bummer. Returned my unit

Sean M
September 16, 2018

Q&A

Please note, Aircraft Spruce's personnel are not certified aircraft mechanics and can only provide general support and ideas, which should not be relied upon or implemented in lieu of consulting an A&P or other qualified technician. Aircraft Spruce assumes no responsibility or liability for any issue or problem which may arise from any repair, modification or other work done from this knowledge base. Any product eligibility information provided here is based on general application guides and we recommend always referring to your specific aircraft parts manual, the parts manufacturer or consulting with a qualified mechanic.

Q: Does this Pilot USA PA-200V intercom work with the current generation FTA-230, FTA-550 and FTA-750L Yaesu Vertex handheld radios?

PER THE MFG - The PA-200V is a 2 Place Mono Intercom designed to be used with your YAESU/VERTEX handheld transceiver. This unit will plug directly into YAESU FTA-550, FTA-750L and VERTEX VXA-100, VXA-150 Transceivers.

Q: Is this product usable for the YAESU FTA-450?

Yes, it is compatible with the Yaesu FTA 450L.

Q: I have a FTA 450L I understand this will plug into my radio. The problem I have is that MT headset has one jack, not 2 for headphones and Mic. Is there a unit that has such a jack?

You will need an adapter to go from single plug to dual for use with this intercom. Please use our Headset Adapter Wizard to find the one you need to convert your headset.

Q: will this work with the 850L?

Yes it will work.
