Overview

	WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.

Features

• Packed with 7 ultra high brightness CREE LEDs for POSITION mode in white color that are the industry state-of-the-art in performance and output lumens, the PosiStrobes feature a significantly lower footprint than competitor lights.

• Packed with 21 ultra high brightness CREE aviation white LEDs for STROBE mode.

• An extremely lightweight, aerodynamic and low-profile design make this the light of choice for any certified aircraft requiring a rear coverage light due to wingtip light coverage zone limits.

• All Aveo lights are waterproof, dust proof, and inert to most environmental conditions as they are all tested to categories of DO-160 exceeding the applicable requirements by far in external laboratories experienced in compliance demonstration of EASA ETSO appliances.

Specifications

• Dimensions (mm): 44.9 mm x 55.6 mm x 30 mm
• Dimensions (inches): 1.769“ x 2.19“ x 1.18“
• Weight: 0.216 lb
• Operating Voltage Range: 9 – 36 V DC
• Input Current – Position: 0.17 A @36V, 0.22 A @28V, 0.41 A @14V, 0.66 A @9V
• Input Current – Strobe: 1.6 A @36V, 1.9 A @28V, 4.2 A @14V, 4.4 A @9V
• Input Power – Position:: 6.2 W @36V, 6.2 W @28V, 5.8 W @14V, 5.9 W @9V
• Input Power – Strobe:: 58 W @36V, 53 W @28V, 59 W @14V, 40 W @9V
• Input Power - Position / Nav - red: 7 W @36V, 7 W @28V, 6.7 W @14V, 7.2 W @9V
• Input Power - Strobe: 39.6 W @36V, 39.2 W @28V, 32.2 W @14V, 26.1 W @9V
• Repetition Rate of Strobe: 48 cycles per minute
• Recommended size of mounting screw: M3
• Ambient Temperature: from -55°C to +85°C from -55°F to +185°F
• Overheat Protection: YES (+85°C)
• Reverse polarity protected: YES
• Transient Voltage: 60V at 2sec max, both polarities
• Under-Voltage Protection (lockout): YES (9V)
• Over-Voltage Protection (lockout): YES (36V)
• Waterproof, Dust-proof, Shock-proof, Vibration-proof: YES

Documents

• AVEO PosiStrobe Manual
• PosiStrobe Titania TSO Certification
• PosiStrobe Titania Drawing
